China Belt Type Multi Grain Sorting Machine
Release time:
2025-07-29
The Belt Type Multi Grain Sorting Machine revolutionizes grain processing with its cutting-edge technology and unmatched efficiency. Designed to sort multiple grain types simultaneously, this machine ensures optimal quality control. Its belt-type mechanism provides seamless movement of grains, minimizing damage and maximizing output. The Belt Type Multi Grain Sorting Machine is the perfect choice for modern agricultural and industrial applications.
Functional Features
● New design
Adopt the German industrial design concept to make the structure design is more stable, optimized for electrical and optical design, improved machine life and stability.
● The brand-newAl intelligent sorting
Independent learning to distinguish good and bad materials, no manual intervention, automatic intelligent sorting.
● New image processing algorithm
Simulation processing algorithm, simplify imaging, minimalist operation, so that you do not learn to use the color selection machine.
● New large-screen operating
15-inch high resolution large screen, optimize the operation interface, the key information at a glance.
● Excellent Camera Image Acquisi- tion System
5400 CCD，industrial lens with multispectrum confocal technology, the minimum resolution of 0.015mm,accurate removal of evil and miscellaneous, glass.
● Superalloy high-frequency solenoid valve
The integrated structure can achieve accurate elimination of more than 800 times per second, helping greater output and loss Lower.
Main Applications
| Black Bean | Kidney Bean | ||
Accept |
Reject |
Accept |
Reject |
| Peanuts | Soy Bean | ||
Accept |
Reject |
Accept |
Reject |
Technical Parameter
| Model | HWT-2S | HWT-3S | HWT-4S | HWT-5S | HWT-6S | HWT-7S | HWT-10S |
| Output (t/h) | 0.5-4 | 1.0-5.0 | 1.5-6.0 | 2.0-7.0 | 2.5-8.0 | 3.0-9.0 | 4.0-11.0 |
| Accuracy (%) | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | 99.99 | ≥99.99 |
| Optimal Carryover Rate (Bad:Good) | >20:1 | >20:1 | >20:1 | >20:1 | >20:1 | >20:1 | >20:1 |
| Weight (kg) | 680 | 840 | 1000 | 1165 | 1310 | 1505 | 2050 |
| Minimum Resoultion (mm) | 0.015mm | 0.015mm | 0.015mm | 0.01 5mm | 0.01 5mm | 0.015mm | 0.015mm |
| Air Consumption (m/min) | 0.5-1.0 | 0.8-1.5 | 1.0-2.0 | 1.3-2.1 | 2.0-3.5 | 2.5-4.3 | 5.0-6.5 |
| Power (Kw) | 1.5 | 2.0 | 2.4 | 3.0 | 3.6 | 4.2 | 6.0 |
| Dimension (L*W*H/mm) | 1244*1570*2090 | 1564*1570*2090 | 1864*1570*2090 | 2184*1570*2090 | 2500*1570*2090 | 2814*1570*2090 | 3756*1570*2090 |
| Power Input (V/Hz) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) |
The Belt Type Multi Grain Sorting Machine revolutionizes grain processing with its cutting-edge technology and unmatched efficiency. Designed to sort multiple grain types simultaneously, this machine ensures optimal quality control. Its belt-type mechanism provides seamless movement of grains, minimizing damage and maximizing output. The Belt Type Multi Grain Sorting Machine is the perfect choice for modern agricultural and industrial applications.
Featuring high-resolution cameras and advanced algorithms, the Belt Type Multi Grain Sorting Machine delivers exceptional accuracy in identifying and removing defective grains. The machine’s customizable settings allow for tailored sorting based on specific criteria, ensuring superior results. Its compact yet sturdy design makes it suitable for various operational setups, from farms to large processing units.
The Belt Type Multi Grain Sorting Machine is built for durability and performance. Its corrosion-resistant materials and easy-to-clean components ensure longevity and hygiene. The machine’s energy-efficient operation reduces power consumption, making it an eco-friendly option. With minimal noise levels, it provides a comfortable working environment for operators.
Choose the Belt Type Multi Grain Sorting Machine to streamline your grain sorting process. Its combination of speed, precision, and reliability makes it a must-have for any grain processing facility. Don’t compromise on quality—opt for the Belt Type Multi Grain Sorting Machine and achieve consistent, high-quality results with every use.
