Hawit Brand Plastic Color Sorter Machine is Desinged to Sort All Kinds of Different Plastics, Such as PVC and PET sorting etc;
The Capacity of This Model can Get Around 1-14Tons/h (According to Comtaminate 3%-5%) with Available Models from 1 Chute to 16 Chutes .
The Ejector of This Model Can Use Hawit Brand , SMC Brand (from Japan), or Martrix Brand (from Etaly) , Which Meets Different Customer Market Requirment .
The Len of Camera is From Toshiba , Japan , The Camera Pixels 5400 .
The Main Available Feature of This Model :
Photo Capture Functions:
Shape Sorting Available;
RGB Technology Sorting ;
More Software Design for Different Products ;
Friendly Using in Touch Screen ;
1.Technical Feature:
*Self-Checking System
Self-test system automatically checks the working status of the camera, control panel and background board, saving you
the time to check all parts before each operation
*One Key Operation System
The user can set the color, shape, size and defect area of the material, and confirm the unqualified material, so that the
machine can automatically set the sorting scheme of the material according to the principle of independent calculation,
intelligent identification and intelligent sorting
*LED Light Control System
With advanced digital stepless automatic dimming technology, LED brightness can be automatically adjusted according to
material sorting requirements and environmental changes. The best sorting performance will be obtained. The latest
technology of LED system can satisfy the requirements of thousands of color recognition, separation and classification.
*Remote Control System
Hawit cloud service technology platform can provide real-time online tracking service monitoring and data collection for
machine operation. It can realize remote control, operation, maintenance and software upgrade, and can detect and solve
LED lamp, electronic, mechanical and adjustment problems
*5400 Camera Pixels
HD industry use CCD camera brings the sorting accuracy to 0.04mm²,easy to separate black spot and light
yellow.
*New Generation of ARM+FPGA Processor Technology extremely increases the sorting capacity to ensure your high
producing ability.
*Latest Ejector Technology makes the ejectors longer life time, lower air consumption, faster speed, easier maintenance
and high sorting accuracy.Hawit brand ejector , SMC ejector or Martrix ejector can be selected to meet different distributor and end user requirment .
*Special Feeding System Design makes each chutes separated and allows you to combine the chutes due to sorting
requirements, decreases the rejection ratio and air consumption.
2. Technical Specification:
Technical Parameter | ||||||
Model No | HWT-4 | HWT-5 | HWT-6 | HWT-7 | HWT-8 | HWT-10 |
Machine weight (Kgs) | 1150 | 1300 | 1500 | 1700 | 1950 | 2250 |
Channels No | 252 | 315 | 378 | 441 | 504 | 630 |
Light source | LED | LED | LED | LED | LED | LED |
Pixel of camera | 5400 | 5400 | 5400 | 5400 | 5400 | 5400 |
Camera Scanning Speed | 16000 | 16000 | 16000 | 16000 | 16000 | 16000 |
Ejector | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) |
Capacity (Tons/h) | 2--3 | 2--3 | 3--4 | 4--5 | 5--6 | 7--8 |
Color sorting accuracy | 99,9% | 99,9% | 99,9% | 99,9% | 99,9% | 99,9% |
Resolutions (mm) | 0,08 | 0,08 | 0,08 | 0,08 | 0,08 | 0,08 |
Power (KW) | 3.6 | 4.1 | 4.7 | 4.7 | 5.0 | 5.4 |
Power supply (Voltage/HZ) | 220/50 (110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) |
Warrantly | One Year | One Year | One Year | One Year | One Year | One Year |
Machine Delivery Time | 25-30 days after Advance Payment | 25-30 days after advance | 20-25 days after advance payments | 20-25 days after advance payments | 20-25 days after advance payments | 20-25 days after advance payments |
Air Comsuption (L/min) | 1300~2100 | 1300-2100 | 2000~3500 | 2500~4300 | 3000~4500 | 5000~6500 |
Compressor Capacity (Kw) | 15 | 15 | 22 | 30 | 30 | 37 |
Machine Dimention(mm) | 1912*1574*2090 | 2226*1574*2090 | 2540*1574*2090 | 2854*1574*2090 | 3168*1574*2090 | 3796*1574*2090 |
Wooden case Packing Dimention (mm) | 2232*1764*2341 | 2546*1764*2341 | 2860*1764*2341 | 3174*1764*2341 | 3488*1764*2341 | 4300*1764*2341 |
Components Suppliers |
|
Camera |
Toshiba Full Color Camera CCD with 5400 pixel |
Lens |
Phoenix customized industrial lens |
Chip |
Intel and ATI brand DSP,FPGA |
Power supply |
Mean Well |
Power switch |
Schneider |
Filter |
SMC |
CCD camera |
The high-end 5400 pixel CCD camera can distinguish the infinitely small spot, and improve the sorting level to a higher level |
Optical System |
Scientific and reasonable optical design, clearer and wider resolution range |
Heat System |
Reasonable heat output device ensures that all parts work at room temperature with better signal-to-noise ratio, which not only improves the sorting accuracy, but also extends the service life of the machine. |
Image System |
More intelligent software can easily identify all kinds of heterochromatic heterogeneous materials and improve the accuracy of selection. |
Human-machine operation |
humanized true color screen, the visual effect is clearer, the operation is easier |
Ejector |
professional high-frequency ejector, save more air, faster reaction speed, higher accuracy, longer life, with intelligent software, to ensure good nesting rate and excellent precision |
3 After Sales Services:
At site service from local distributor ;
Free software upgrade services ;
One year warranty and free maintenance;
Chinese Engineers available to service machinery overseas.
24 Hours on line Guide from manufacture
A:Sample material for testing use is welcome. a working video will be offered for sorting result inspection.
5.Machine Working Performance
