Model Series: HWT-ST4 to HWT-ST10 (1–16 Chutes Available)
All Capacity Options for Peanut Processing
The Hawit peanut color sorter is specially engineered for sorting all varieties of peanuts, and has been widely installed in both the Indian market and the Chinese domestic market.
With a flexible capacity of 1–14 tons per hour (based on approx. 3%–5% contamination), the series offers scalable solutions from 1 to 16 chutes.
Ejector Options:
Available with Hawit brand, SMC (Japan), or Matrix (Italy) ejectors to meet different market requirements.
Camera & Lens:
Equipped with a Toshiba (Japan) full-color CCD camera with 5400 pixels for superior image clarity.
The Main Available Feature of This Model :
Photo Capture Functions:
Shape Sorting Available;
RGB Technology Sorting ;
More Software Design for Different Size of Peanut ;
Friendly Using in Touch Screen ;
Peanut Color Sorter Machine with All Capacity Available
1.Technical Feature:
*5400-Pixel High-Resolution Camera
The industrial-grade HD CCD camera achieves sorting accuracy down to 0.04 mm², easily separating black spots, light-yellow defects, and other impurities commonly found in peanuts.
*One-Key Intelligent Operation System
Users define the peanut's color, shape, size, and defect area. The machine then autonomously calculates, intelligently identifies, and automatically sets the optimal sorting scheme.
*New-Generation ARM+FPGA Processor
Extremely increases sorting capacity to support high-volume peanut processing lines.
*Latest Ejector Technology
Delivers longer ejector lifespan, lower air consumption, faster response, easier maintenance, and high sorting accuracy. Ejectors can be customized (Hawit, SMC, or Matrix) to meet varying distributor and end-user demands.
*LED Light Control System
Advanced digital stepless automatic dimming technology automatically adjusts LED brightness based on peanut sorting requirements and environmental changes, ensuring optimal performance across thousands of color recognition tasks.
*Remote Control System
The Hawit cloud service platform provides real-time online tracking, service monitoring, and data collection. It enables remote control, operation, maintenance, and software upgrades, and can diagnose issues related to LED lamps, electronics, and mechanics.
*Self-Checking System
The self-test system automatically checks cameras, control panels, and background boards before each operation, saving time on manual pre-checks.
*Special Feeding System Design
Each chute operates independently and can be flexibly combined according to sorting requirements, effectively reducing the rejection ratio and air consumption during peanut processing.
| Technical Parameter | ||||||
| Model No | HWT-ST4 | HWT-ST5 | HWT-ST6 | HWT-ST7 | HWT-ST8 | HWT-ST10 |
| Machine weight (Kgs) | 1150 | 1300 | 1500 | 1700 | 1950 | 2250 |
| Channels No | 252 | 315 | 378 | 441 | 504 | 630 |
| Light source | LED | LED | LED | LED | LED | LED |
| Pixel of camera | 5400 | 5400 | 5400 | 5400 | 5400 | 5400 |
| Camera Scanning Speed | 16000 | 16000 | 16000 | 16000 | 16000 | 16000 |
| Ejector | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) | Hawit Brand (Optional); SMC Brand (Optional) |
| Capacity (Tons/h) | 2--3 | 2--3 | 3--4 | 4--5 | 5--6 | 7--8 |
| Color sorting accuracy | 99,9% | 99,9% | 99,9% | 99,9% | 99,9% | 99,9% |
| Resolutions (mm) | 0,08 | 0,08 | 0,08 | 0,08 | 0,08 | 0,08 |
| Power (KW) | 3.6 | 4.1 | 4.7 | 4.7 | 5.0 | 5.4 |
| Power supply (Voltage/HZ) | 220/50 (110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) | 220/50(110/60) |
| Warrantly | One Year | One Year | One Year | One Year | One Year | One Year |
| Machine Delivery Time | 25-30 days after Advance Payment | 25-30 days after advance | 20-25 days after advance payments | 20-25 days after advance payments | 20-25 days after advance payments | 20-25 days after advance payments |
| Air Comsuption (L/min) | 1300~2100 | 1300-2100 | 2000~3500 | 2500~4300 | 3000~4500 | 5000~6500 |
| Compressor Capacity (Kw) | 15 | 15 | 22 | 30 | 30 | 37 |
| Machine Dimention(mm) | 1912*1574*2090 | 2226*1574*2090 | 2540*1574*2090 | 2854*1574*2090 | 3168*1574*2090 | 3796*1574*2090 |
| Wooden case Packing Dimention (mm) | 2232*1764*2341 | 2546*1764*2341 | 2860*1764*2341 | 3174*1764*2341 | 3488*1764*2341 | 4300*1764*2341 |
On-site support from local distributors
Free software upgrade services
One-year warranty with free maintenance
Chinese engineers available for overseas service trips
24-hour online guidance from the manufacturer
