S Model Color Sorter Machine With 5 Chutes 315 Chennels

Hawit S model 5 chutes machine

S Model Color Sorter Machine With 5 Chutes 315 Chennels

Hawit  S model 5 Chutes Rice Color Sorter Machine Can Work with Sorting All Kinds of Different Rice , Such as Basmati , Parboiled Rice, Raw Rice etc;

The Capacity of This Machine can Be Reach Around 2-3 Tons/h (According to Comtaminate 3%-5%) ;

The Ejector of This Model Can Use Hawit Brand , SMC Brand (from Japan), or Martrix Brand (from Etaly) , Which Meet the Different Customer Requirment .

The Len of Camera is From Toshiba , Japan , The Camera Pixels 5400 .

The Main Available Feature of This Model :

15 Inch Display;

Glass mixed in Rice can be Sorted ;

Photo Capture;

Shape Sorting Available

Remote Opertation from Manufacture in China .

Reverse Sorting Available ;

Glass Distance Design upto 350 mm





A. Machine Feature



1.  High quality ejector with 5-10 billion ejections life low air consumption

2. RGB full color tri-chromatic CCD image acquisition system.

   High camera resolution 5400 pixel identifying tiny defects up to 0.01mm2

3. Most unique intelligent LED with cold shadowless light source and super long life span, high lighting efficiency
4. Accurate dust collecting position design to secure sorting room spotlessly clean keeping high identification
5. Strong industry-grade digitization processor, image acquisition and processing in high speed, consistency of signal path and signal reliability is secured
6. Excellent combination of mechanical structure and tri-chromatic control system, guarantee 99.999% accuracy and amazing 50:1 rejection rate.
7. International high-end full-color line scan technology, DSP + FPGA processing the international forefront of technology, combining a variety of colors and shapes model complex algorithms, to provide "color selection + shape selected" function for different materials, a variety of modes set free.

 8.Photo Capture Function; China Manufacture Remote Operation; 15 Inch Display;

Low Temprature; RGB Spectrum Technology; Mobile Operation; Glass Distance Upto 350 mm ; Glass Sorting Technology ; Shape Sorting Technology;



B.Machine Parts Details :



Technical Parameter
Model No HWT-SR5
Machine weight (kgs) 1300
Channels No 315
Light source LED
Pixel of camera 5400
Camera Scanning Speed 16000
Ejector Martix Ejector From Etaly
Capacity (Tons/h) 2--3
Color sorting accuracy 99,9%
Resolutions (mm) 0,08
Power (KW) 4.1
Power supply (Voltage/HZ) 220/50(110/60)
Warrantly One Year
Machine Delivery Time 25-30 days after advance
Air Comsuption (L/min) 1300-2100
Compressor Capacity (Kw) 15
Machine Dimention(mm) 2226*1574*2090
Wooden case Packing Dimention (mm) 2546*1764*2341



Components Suppliers

Camera

  Toshiba Full Color Camera CCD with 5400 pixel

Lens

  Phoenix customized industrial lens

Chip

  Intel and ATI brand DSP,FPGA

Power supply

  Mean Well

Power switch

  Schneider

Filter

  SMC



CCD camera

The high-end 5400 pixel CCD camera can distinguish the infinitely small spot, and improve the sorting level to a higher level

Optical System

Scientific and reasonable optical design, clearer and wider resolution range

Heat System

Reasonable heat output device ensures that all parts work at room temperature with better signal-to-noise ratio, which not only improves the sorting accuracy, but also extends the service life of the machine.

Image System

More intelligent software can easily identify all kinds of heterochromatic heterogeneous materials and improve the accuracy of selection.

Human-machine operation

humanized true color screen, the visual effect is clearer, the operation is easier

Ejector

professional high-frequency ejector, save more air, faster reaction speed, higher accuracy, longer life, with intelligent software, to ensure good nesting rate and excellent precision



C.Sorting Perfornamce
